    Benefits & Features

    • Successfully Forcible AttackTested by BRE to SR1, SR2 & SR3 resisting an intensive attack test program in accordance with LPS 1175: Issue 7.3
      Security Rating 1
      – series of attacks lasting 1 minutes
      Security Rating 2
      – series of attacks lasting 3 minutes
      Security Rating 3
      – series of attacks lasting 5 minutes
    • The Hinged Gate is a swing security gate, which is ideal for sites where there is a limited area for the runback of a sliding gate
    • Hinged Gate leaves can be automated with our range of Trojan or Dutyman Actuators

    Trojan Actuator

    • Designed to automate larger, heavier gates
    • 100% duty rating – designed for continuous operation
    • Underground and surface mounted models available

    Dutyman MkII Actuator

    • A surface mounted, self-contained electro-mechanical drive mechanism
    • The actuator will operate double-leaf gates up to 10m and heights up to 4m *
    • 100% duty rating – designed for continuous operation


    • 100/200mm Traffic Light System
    • High Security Cabinet
    • Can be interfaced to any access control systems Safety
    • Vehicle detector loops
    • Safety photocell beams
    • Flashing beacons
    • Audible alarm
    • Safety Edge

    Civil Requirements

    • Double Leaf with small Dutyman Drive (millimetres) Gate post foundation L: 1000 x W: 1100 x D: 900 Ground stop L: 600 x W: 600 x D: 300
    • Note: Power and control wiring ducts to be incorporated into foundations

    Electrical Requirements

    • Dependent on Automation

    Depending on configuration

    This is subject to a risk assessment to ensure the automatic equipment complies to BS EN 12453
